Product Details
25 mm (1") Pro-Flo® Series Clamped Metal Pump P2 Metal Pump
AIR INLET
1/4" FNPT
LIQUID INLET
25 mm (1")
LIQUID DISCHARGE
19 mm (3/4")
CONNECTION TYPE
NPT/BSPT (Threaded)
MAX SUCTION LIFT CAPABILITY
Rubber – 5.2 m (17.0') Dry, 9.0 m (29.5') Wet
TPE – 7.6 m (25.0') Dry, 9.0 m (29.5') Wet
Full-Stroke PTFE – 4.7 m (15.3') Dry, 9.0 m (29.5') Wet
Reduced-Stroke PTFE – 2.8 m (9.1') Dry, 9.0 m (29.5') Wet
MAX FLOW RATE
Rubber – 172 lpm (45.5 gpm)
TPE – 171 lpm (45.2 gpm)
Full-Stroke PTFE – 167 lpm (44.1 gpm)
Reduced-Stroke PTFE – 155 lpm (41 gpm)
MAX PRESSURE
8.6 bar (125 psi)
MAX DIAMETER SOLIDS
3.2 mm (1/8'')
DISPLACEMENT PER STROKE *
Rubber – 0.3 L (0.08 gal)
TPE – 0.3 L (0.08 gal)
Full-Stroke PTFE – 0.3 L (0.08 gal)
Reduced-Stroke PTFE – 0.3 L (0.08 gal)
* 1 cycle = 2 strokes
